MULTI PURPOSE EXHAUST FAN BRW650

ABOUT THIS MODEL This Ecodrive®-powered silent exhaust fan comes with 850 m3/hr airflow to whisk away odours, steam, stale air and humidity in seconds – efficiently reducing airborne bacteria and preventing mould growth. It is designed to be installed through the roof or wall and suitable for almost any room in your unit, apartment, townhouse, single or multi-storey house. Please note that installing a door vent or ensuring a suitable gap below the door is essential for this exhaust fan to effectively remove steam and significantly minimise condensation in the bathroom. Box contains 1x Ecodrive® motor with 200mm backdraft shutter, 1x 200mm metal pipe, 1x 4m length of 200mm diameter flexi-ducting, 4x 12mm button head screws, 1x wall hanging bracket plus 1x white square recessed diffuser (DF-W). The BRW650 can also be vented to 2 adjacent rooms with the optional DVK650 ducting kit. Both the BRW650 and DVK650 are now available in one convenient bundle called the BRW652 WARRANTIES 3 Years Motor Warranty DIMENSIONS 303.0 mm WIDTH X 303.0 mm DEPTH X 89.0 mm HEIGHT . Improves indoor air quality Hygienically removes odours and airborne bacteria without the use of toxic chemicals. Powerful silent extraction Powerful silent extraction – the externally-mounted German-engineered Isodrive® motor silently whisks away odours, steam, stale air and humidity in seconds. Perimeter Aspiration Uses an additional panel to create a Venturi effect along its edges for more intensive and effective extraction. Energy-efficient The Schweigen Isodrive® motors are amongst the most energy-efficient in the market, requiring just 57 watts of power to run on some models. Discreet design Sleek profile integrates seamlessly into the ceiling for a modern, minimalist look. Multi-purpose ventilation Suitable for use in the bathroom, bedroom, toilet, garage, wine cellar or laundry room. Flexible & functional Can be easily installed by a professional, and vented to 2 rooms with the optional venting kit. Frequently Asked Questions Why can’t I hear the Schweigen rangehood running? Schweigen’s Isodrive® technology places the motor remotely in the roof cavity, wall or ceiling void — away from the kitchen. At low speeds the rangehood is virtually silent, because the only sound source is air moving through the filters, not a motor above the cooktop. What does Schweigen rangehood installation involve? Installation costs are typically the same as a standard rangehood. The remote motor unit is installed in the ceiling, roof cavity or bulkhead with flexible ducting. Most Australian states require external venting to outside — check your state building authority requirements. Contact us for a referral to an experienced Schweigen installer near you. Is the Schweigen rangehood covered by Australian warranty? Yes. Schweigen rangehoods sold through authorised Australian dealers carry a full Australian warranty. Airdry is an authorised Schweigen dealer — all products purchased through us are covered and supported locally. Technical specifications sourced from Schweigen — schweigen.com.au
